Features
• Naturally hydrophilic, no need for pre-wetting
• High flow rate, low DP and long service life
• Excellent integrity provides good particle removal and sterilization efficiency
• Non-contact welding adopted, no adhesives, low extractables
• Excellent chemical compactivity
• Tolerance for in-line steam sterilization
• Gross integrity
Applications
• Large volume parenterals (LVP) injections and antibiotic filtration
• Physiological saline solution and other solvents filtration of microorganism removal
• Pure Water and water-based filtration of microorganism removal\
Dimension
•Out Diameter 2,72” (69 mm)
•Length 5” (125 mm)
•10” (254 mm)
•20” (500 mm)
•30” (750 mm)
•40” (1000 mm)
Quality
• Filter Cartridges are manufactured in a clean room environment
• Manufactured according to ISO9001:2015 certified Quality Management System 33
Material of Constructions
•Filter medium Nylon N66
•Support/Drainage PET
•Cage/Core Polypropylene
•Endcap Polypropylene and Insert
Performance
• Max Operating Temperature 80 °C
• Max Operating DP Forward 4.0 bar @ 25 °C
Forward 2.4 bar @ 80 °C
• SIP 125 °C , 30min
