KP cellulosic depth media capsule filter

KP cellulosic depth media capsule filter

KP cellulosic depth media capsule filter have been designed for simple, quick, and efficient filtration of fluids used in laboratories, pilot, and small scale applications. The family of products is particularly suitable for high loading liquid applications. The compact design of the filters with respect to the filtration area, reduces hold-up volume and optimizes performance. Multiple pore size options is assembled in all polypropylene construction for excellent chemical compatibility.

The cellulosic depth media is structured in a stacked disk format to provide optimal flow. No adhesives, binders, surfactants are used in the process of manufacture.

Category:

Typical Applications
• Prefiltration
• Secondary clarification
• Cell culture harvest
• Cell culture clarification Protein aggregate removal

Filtration Area
• Single layer:1300cm^2/10’’
• Double layer:650cm^2/10”
Material construction
• Filter Media:
     -Cleaned and bleached cellulose
     -Natural filter aid (kieselguhr, perlite)
• Media Support: Polypropylene
• End Caps: Polypropylene
• Inner Core: Polypropylene
• Outer Cage: Polypropylene
Fitting Option
• 1.5”TC
• 1/2” Hose Barb
Vent/Drain Option
• Staubli
• Stepped hose barb
Toxicity
•All materials meet the specifications for biological safety
•per USP Class Vl-121’C for plastics
Capsule Integrity
•Minimum burst pressure:123.5psi(8.5barg)
