Product features
● Wide chemical compatibility
● High dirt hold capacity
● High retention
● Thermal bonding
● Non-fiber releasing
Typical Application
● Process Water
● Vinegar
● Aqueous solutions
● Beer, Wine and Spirits
● Juice, Soft Drinks, Edible Oils
● Bulk Chemicals
● Pharmaceutical intermediates
| Filtration Area | 2.5’’ = 1480 cm2
5’’ = 2650 cm2 10’’ = 5500 cm2 20’’ = 11000 cm2 30’’ = 16500 cm2 40’’ = 22000 cm2 |
| Filter Media | PP |
| Media Support | PP |
| End Caps/ lner Core/Outer Cage: | PP |
| Sealing Method | Thermal Bonding |
| Maximum Operating Temperature | 80°C |
| Maximum Operating Pressure | 5 bar @25°C |
| Part No. | Pore Size | Application | Sterilization | Size | Fittings | Vent/Drain | |
|---|---|---|---|---|---|---|---|
| CIKPP | 0060=0.6μm | G = Gen Purpose | N = Not Sterile | SS = 2.5’’ | 5TC = 1.5″ TC | SS = St/St | |
| 0100=1μm | P= Premier | LL=5’’ | 2HB = 1/2″ HB | HH = HB/HB | |||
| 0200=2μm | TE=10’’ | 4HB = 3/4″ HB | SH = St/HB | ||||
| 0300=3μm | TW=20’’ | T2B = 1.5″ TC/ 1/2″ HB | HS = HB/St | ||||
| 0500=5μm | TH=30’’ | T4B = 1.5″ TC/ 3/4″ HB | |||||
| 0700=7μm | FO=40’’ | 2BT = 1/2″HB/ 1.5” TC | |||||
| 1000=10μm | 2B4 = 1/2″HB/ 3/4″ HB | ||||||
| 2000=20μm | 4BT = 3/4″HB/ 1.5″ TC | ||||||
| 3000=30μm | 4B2 = 3/4″HB/ 1/2″ HB | ||||||
| 5000=50μm |
